The Wilcox RAPTAR Xe is the next generation in the RAPTAR line of products. As a class 3B high power laser aiming device, the RAPTAR Xe is designed specifically for the military and law enforcement markets. The RAPTAR Xe provides snipers and advanced tactical shooters increased accuracy and precise engagement of targets at extremely long ranges.

Compared to it’s predecessor, the RAPTAR Xe is a smaller, lighter, and stronger laser aiming device which significantly increases first-round hit capability. The built-in networking capabilities and user interface give the RAPTAR Xe superior maintenance and replenishment connectivity with key auxiliary devices. These leading-edge features increase the operator’s lethality and situational awareness.

FEATURES & BENEFITS

SPECIFICATIONS – HIGH POWER

Battery Life: Over 8 Hrs
Immersion: 1 meter for 1 hour
Boresight Retention: <.5 mrad
Laser Type: Diode Based Laser Transmitter & APD Receiver
Laser Classification/Wavelength: Class 1/1.55um
Beam Divergence: < 1 mrad
Minimum Range: 20 meters
Ranging Operation at 24C: >2000 ranges
Max Range @ 30% Reflectivity: 2000 meters Man Size Target
Max Range @ 30% Reflectivity: 3000 meters NATO Size Target
Laser Type/Wavelength/Power: Red Visible Laser/ 660nm/ 75mW
Laser Type/Wavelength/Power: Infrared Laser/ 850nm/ 30mW
Laser Type/Wavelength/Power: Infrared Illuminator/ 860nm VCSEL/ 90mW

The post RAPTAR Xe High Power appeared first on 1776 Sporting Goods.

The Wilcox RAID Xe High Power is the culmination of years of operator feedback and leading-edge technical advancements. The result is a compact, ergonomic aiming and illumination device with a uniquely rich feature set that achieves the highest standard of optical performance.

Military and law enforcement operators face an array of unique challenges in low or no light environments where quick target acquisition and identification are required. The RAID Xe represents a complete, robust solution for any operator requiring a high degree of awareness, flexibility and accuracy to ensure mission success.

Also available, the RAID Xe Low Power Laser Aiming Device.

FEATURES & BENEFITS

SPECIFICATIONS – HIGH POWER

Laser Type/Wavelength/Power*: Red Visible Laser/660nm/75mW
Laser Type/Wavelength/Power*: Green Visible Laser/520nm/12mW
Laser Type/Wavelength/Power*: Infrared Laser/850nm/30mW

The post RAID Xe High Power appeared first on 1776 Sporting Goods.

The Wilcox RAID Xe Low Power is the culmination of years of operator feedback and leading-edge technical advancements. The result is a compact, ergonomic aiming and illumination device with a uniquely rich feature set that achieves the highest standard of optical performance.

Military and law enforcement operators face an array of unique challenges in low or no light environments where quick target acquisition and identification are required. The RAID Xe represents a complete, robust solution for any operator requiring a high degree of awareness, flexibility and accuracy to ensure mission success.

The RAID-Xe provides a smaller, lighter, stronger laser aiming device with superior, uncompromising performance. The ultimate beam clarity and uniformity aide rapid target acquisition and the built-in networking capabilities give the RAID-Xe superior maintenance and replenishment connectivity, all increasing the warfighter’s lethality and situational awareness. The RAID-Xe Low Power version is only available with a co-aligned visible red laser.

The Wilcox RAID Xe is a complete ‘Turn-Key’ solution for any environment where reliability, quick target acquisition and identification are required for successful outcomes, it truly is State of the Art in laser sighting systems.

The post RAID Xe Low Power appeared first on 1776 Sporting Goods.

• Class 1 Eye Safe Operation
• IR Laser
• Powered by: One AA Battery
• Quick Release HT Mount
• Fully Adjustable Windage / Elevation
• Remote Cable Pad Activation
• Momentary or Constant On Operation

The post OTAL-C appeared first on 1776 Sporting Goods.

Supplied with:

• Quick-Release Mount
• 7″ Remote Cable Pressure Pad Switch
• (1) 3-Volt 123A Lithium Battery

  The third generation DBAL-A³ (Dual Beam Aiming LASER) is equipped with an Infrared Pointer, an Infrared Pointer/Illuminator and a Green Ultra Powerpoint visible pointer, which is 5 times more visible than traditional Red LASER’s. The DBAL-A3  allows you to sight in the Visible LASER and Co-Aligns the IR LASER. The DBAL-A3 also has the illuminator. In contrast, the DBAL-I² does not offer the Dual Beam Co-Alignment. You will need to sight in your IR LASER with Night Vision and your Visible LASER separately. Also, there is no illuminator on the DBAL-I².

     The DBAL-A³ provides the same overall functionality as its predecessor, the DBAL-A², but with enhancements that include dual remote cable ports that incorporate a tactical light by plugging the supplied Y-cable into both the light and the visible override port on the back of the laser housing. Pressing the Y-cable pressure pad will simultaneously activate the tactical and the visible laser. The second pressure pad, plugged into the standard port, will activate the infrared laser functions. This unique feature allows for immediate transition from low light to daylight operations by simply choosing which pressure pad to activate.

Designed to meet MIL-STD-810G requirements for extreme environmental conditions, the DBAL-A³ provides users with the utmost advantage in ever-changing battlefield conditions.

This lightweight, waterproof unit is equipped with a Green Ultra Power Point LASER which is designed for maximum daytime visibility and clear, crisp visibility at night. The Green LASER offers faster target acquisition and is 5 times more visible than traditional Red LASER’s. A third option involves an Infrared pointer, which meets MIL-STD-810G for reliability under harsh environmental conditions.

Features an adjustable IR illuminator for better illumination at longer ranges, dual activation switches and high/low power modes. The DBAL-A3 class 1/3R Civilian, based on the standard issue DBAL-A3 for U.S. war fighters, brings the latest advances in IR and LASER technology to the civilian market with its dual beam reliability for extreme accuracy in low- and no-light maneuvers. In addition, the DBAL-A3 is the first to feature new de-focused adjustable IR illumination technology to enable both mid-range and close quarter target acquisition.

Manufactured in the USA using the finest quality materials, with a 3 Year Warranty.

EXPORT LICENSE REQUIRED.

Features

•   Available in Black or Tan (Desert Sand)
• Rugged Aerospace Aluminum housing, MIL-SPEC Type III Hardcoat anodized
• Hi-Power and Lo-Power modes of operation
• Mounting holes for a Flip-Up front sight, Sub-Miniature Red Dot Sight or a MIL-SPEC-1913 top rail
• 6061-T6 Aircraft Aluminum, MIL-SPEC Type III Hardcoat Anodized Housing
• ESD Compliant for air worthiness
• Fully adjustable for Windage and Elevation
• Single adjustment mechanism for both Visible and IR pointers
• Meets MIL-STD-810G for adverse environmental conditions
• Activation/Low Battery indicator light (123A Battery only)
• Dual remote cable ports incorporate Tactical Lights
  –  Override cable switch activates the Visible LASER & Tactical Light simultaneously
  –  Standard remote cable switch activates the infrared functions
  –  Single tap for momentary activation,
  –  Double tap for Continuous ON mode for 5 minutes or until pressed again
• Optional Optical Diffuser and Neutral Density Filter Available
• Waterproof to up to 5 Meters (Military Models Waterproof to 20 Meters)

DBAL-A3 PN: 9008 (Black)

LASER Type:

Visible Green – Class IIIa

IR LASER – Class IIIb

IR Illuminator – Class IIIb

Visible Green Laser – Class IIIa 532nm

Beam Divergence: <0.8 mRAD

High Output: <5mW

Low Output: 1mW

Range/Visibility (Day) 15m (16yds)

Range/Visibility (Night) 750m (820yds)

Power Output:

IR LASER Pointer <0.7mW (non LED)

Beam Divergence: <0.8 mRAD

Wavelength:  850nm

Range/Visibility (Night): >250m (274 yards)

IR Illuminator: <4mW (non LED)

Beam Divergence: 95 – 195 mRad

Wavelength:  850nm

Range/Visibility (Night) ≤1000m (1100yds)

850nm Low Output: <300mW: Yes

High/Low Operation: Yes

Includes Pressure Pad Switch: Yes

Pushbutton Activation: Yes

Remote Cable Activation: Yes (Pressure Pad Switch)

Momentary On: Yes

Constant On: Yes

Windage/Elevation Adjustable: Yes

Quick Detachable HT Mount: Yes

Mounts to MIL-STD 1913 Picatinny: Yes

(1) CR123A Battery Operation: Yes

Battery Life: >3 Hours

Waterproof: Submersion in Meters: 5 meters

Weight in ounces: 8oz / Weight in grams: 227g

Size: Length = 3.5″ (91.4 mm) / Width = 2.75″ (69.9 mm) / Height = 1.59″ (40.4 mm)

Aircraft Aluminum 6061-T6 w/Class III Hard Anodized Housing: Yes

Temperature Range: 40°C(-40°F) to +65°C(149°F)

Max Storage Temperature: 80°C (176°F)

Warranty in Years: 3 Years

Optional Accessories:

• 9102 (Old LDI PN: FA05779-01) Exit Port Cover – IR Illuminator – Black
• 9103 (Old LDI PN: FA06883-01) Exit Port Cover – Visible/IR Pointer – Black
• 9105 (Old LDI PN: FA06883-03) Exit Port Cover – Visible/IR Pointer – Tan
• 9111 (Old LDI PN: FA05805-01) CR123A Battery Cap – Black
• 9112 (Old LDI PN: FA05805-03) CR123A Battery Cap – Tan
• 9113 (Old LDI PN: FA06393-01) CR23A Battery Cap STRAP (For 9111) – Black
• 9114 (Old LDI PN: FA06393-03) CR123A Battery Cap STRAP (For 9112) – Tan
• 9120 (Old LDI PN: FA05063-7) 7″ Right Angle Remote Cable Pressure Pad Switch
• 9121 (Old LDI PN: FA05219-7) 7″ Straight Remote Cable Pressure Pad Switch
• 9135 (Old LDI PN: FA05233-01) Set of 5 Optical Pattern Generators, IR Pointer – Black
• 9137 (Old LDI PN: FA05238-01) 80° Optical Diffuser – Black
• 9138 (Old LDI PN: FA05349-01) Neutral Density Filter, Dust Cover – Black
• 9145 (Old LDI PN: FA06146-01) Dual Remote Cable Pressure Pad Switch – Black

The post DBAL-A3 appeared first on 1776 Sporting Goods.

Dual Beam Aiming LASER

Supplied with:

Quick Release HT Mount, Battery, (1) 3-Volt 123A Lithium Battery, 7″ Right Angle Remote Cable Pressure Pad Switch (Specify cable length if different from standard)
– Integrated Momentary Remote Pressure Pad Switch & Activation Switch
– Single-Tap – Enables momentary activation
– Double-Tap – Instantly activates the LASER in a 5 Minute continuous “ON Mode”.
– Built-in safety returns the unit to momentary activation after 5 minutes.
– The Pressure Pad provides a tactile (silent) click that indicates when the switch has been activated

  The powerful DBAL-D² is power packed with a focusable IR LASER illuminator, a Class 1 Eyesafe Infrared Aiming LASER Pointer for use with Night Vision Devices, and a visible Green Ultra Power Point Aiming LASER pointer, which is five times more visible than traditional Red LASERS and the maximum allowed by law for maximum daytime visibility. When every second counts, the versatile DBAL-D² is the right choice for any mission. Designed for maximum operational versatility while keeping the weight down and size to a minimum, the DBAL-D² is Combat Ready and considered to be the most innovative and multi-functional LASER system on the market today.

The DBAL-D² is the commercial version of its predecessor, the DBAL-A². The DBAL-D² is equipped with a visible laser pointer, Class 1 IR laser pointer, and a high definition, aspherical, telescopic IR LED illuminator that outperforms all other IR illumination devices.

The DBAL-D² feature a new streamlined housing, improved Windage and Elevation adjusters and a single activation switch. Frequently compared to the plastic-molded AN/PEQ-15, the DBAL-D² delivers superior operational longevity due to its all metal housing and mounting system.

EXPORT LICENSE REQUIRED.

Features

• Rugged aerospace aluminum housing
• MIL-SPEC Type III Hardcoat anodized
• Instantly switch between LASER functions: Visible Pointer only – IR Pointer only – IR Illuminator only
• Infrared Pointer & Infrared Illuminator combined
• Co-Aligned Visible & IR Aiming LASER’s
• Single adjustment mechanism for both IR & Visible LASERs
• Hi-Power & Lo-Power (Class I) modes of operation
• 2° to 30° adjustable IR Illuminator
• Fully adjustable for Windage & Elevation for Pin-Point Accuracy
• Collimated IR illuminator enhances Night Vision performance
• Activation and Low Battery Indicator Light
• Meets MIL-STD-810F for adverse environmental conditions
• Mounts on all MIL-SPEC-1913 rails
• Positive On/Off Kill Switch prevents accidental activation
• Precision glass lens produces a virtually round laser point
• Waterproof to 20 Meters

LASER Type:

Visible Green – Class IIIa

IR LASER – Class I LED

IR Illuminator – Eye Safe

Visible Green Laser – Class IIIa 532nm

Beam Divergence: <0.8 mRAD

High Output: <5mW

Low Output: 1mW

Range/Visibility (Day) 15m (16yds)

Range/Visibility (Night) 750m (820yds)

Power Output:

IR LASER Pointer <0.7mW (non LED)

Beam Divergence: <0.8 mRAD

Wavelength:  850nm

Range/Visibility (Night): >250m (274 yards)

IR Illuminator: <600mW LED

Beam Divergence: 2° to 30°

Wavelength:  850nm

Range/Visibility (Night) ≤1000m (1100yds)

850nm Low Output: <300mW: Yes

High/Low Operation: Yes

Includes Pressure Pad Switch: Yes

Pushbutton Activation: Yes

Remote Cable Activation: Yes (Pressure Pad Switch)

Momentary On: Yes

Constant On: Yes

Windage/Elevation Adjustable: Yes

Quick Detachable HT Mount: Yes

Mounts to MIL-STD 1913 Picatinny: Yes

(1) CR123A Battery Operation: Yes

Battery Life: >3 Hours

Waterproof: Submersion in Meters: 5 meters

Weight in ounces: 8oz / Weight in grams: 227g

Size: Length = 3.5″ (91.4 mm) / Width = 2.75″ (69.9 mm) / Height = 1.59″ (40.4 mm)

Aircraft Aluminum 6061-T6 w/Class III Hard Anodized Housing: Yes

Temperature Range: 40°C(-40°F) to +65°C(149°F)

Max Storage Temperature: 80°C (176°F)

Warranty in Years: 3 Years

Optional Accessories:

• 9103 (Old LDI PN: FA06883-01) Exit Port Cover – Visible/IR Pointer – Black
• 9105 (Old LDI PN: FA06883-03) Exit Port Cover – Visible/IR Pointer – Tan
• 9111 (Old LDI PN: FA05805-01) CR123A Battery Cap – Black
• 9112 (Old LDI PN: FA05805-03) CR123A Battery Cap – Tan
• 9113 (Old LDI PN: FA06393-01) CR23A Battery Cap STRAP (For 9111) – Black
• 9114 (Old LDI PN: FA06393-03) CR123A Battery Cap STRAP (For 9112) – Tan
• 9120 (Old LDI PN: FA05063-7) 7″ Right Angle Remote Cable Pressure Pad Switch
• 9121 (Old LDI PN: FA05219-7) 7″ Straight Remote Cable Pressure Pad Switch
• 9135 (Old LDI PN: FA05233-01) Set of 5 Optical Pattern Generators, IR Pointer – Black
• 9137 (Old LDI PN: FA05238-01) 80° Optical Diffuser – Black
• 9138 (Old LDI PN: FA05349-01) Neutral Density Filter, Dust Cover – Black
• 9145 (Old LDI PN: FA06146-01) Dual Remote Cable Pressure Pad Switch – Black

SYSTEM DESCRIPTION

     The DBAL-D² is a Class IIIa laser device that features a Visible Pointer for daylight and low light operations, as well as an Infrared Pointer and Infrared Illuminator for use with Night Vision Devices. The IR beams can be operated individually or in combination, in both low power (LO PWR) and high power (HI PWR) settings.
The DBAL-D² emits a highly collimated beam of IR light for precise aiming of the weapon and a separate IR Illuminator for the target or target area. The IR Illuminator is equipped with an adjustable bezel to vary the size of the illumination beam based on the size and distance to the target. The Visible Pointer and the IR Pointer are co-aligned. The Visible Pointer can be used to boresight the device without the requirement of a Night Vision Device and will simultaneously boresight the IR Pointer.
The DBAL-D² can be used as either a handheld illuminator/pointer or it can be weapon mounted using the Throw Lever Mount. In the weapon mounted mode, it can be used to accurately direct fire as well as illuminate and identify targets.
When the Safety Screw is installed in the rear of the DBAL-D² housing, it prevents the operator from accessing the, HI PWR modes of operation.

DBAL-D² Item Description

1) Battery Cap and Compartment

2) Infrared Illuminator

3) Throw Lever Mount

4) Visible Pointer

5) Boresight Adjusters

6) Infrared Pointer

The post DBAL-D2 appeared first on 1776 Sporting Goods.

The post FUSION G62 appeared first on 1776 Sporting Goods.

Product Overview

The Wilcox FUSION SYSTEM is a light weight integrated modular rifle forearm powered by one CR123 Battery. This all in one holistic
solution powers a reflex sight, red visible laser, IR laser and fixed IR illuminator, as well as a SureFire dual spectrum head with white and
IR light. Designed to integrate into commonly used weapon accessories, this all in one modular system that can be adjusted on the fly
and controlled ambidextrously by the shooter. The FUSION SYSTEM is the next generation of power management and control system

Features & Benefits

• FUSION SYSTEM integrates a reflex sight, red visible aiming laser, infrared (IR) aiming Laser, a fixed IR illuminator, and iron sights all co–aligned on one optical bench.
• One single precision adjuster for each plane (windage and elevation)
• Trajectory switch adjusts POA/POI for two preset firing solutions.
• White/IR light features 3 on the fly illumination levels from 0-300 lumens (white) and 0-120mW (IR).
• Dual battery management system features primary and reserve power supply.
• All power points are sealed when not being used to keep out water and other elements.
• Silicone triangular grip pad tiles diffuse heat generated from weapon use.
• 3X magnifier kit sold separately.

Specifications

Red Dot Sight Plane Height Above the Rail: 1.500”
Color: Black Matte Finish
Water Resistance: Waterproof to 1 Meter
Battery Type: (2) 123A Lithium Battery (1) primary (1) reserve
Battery Life: Over 10 Hrs on Dual High IR Laser Only
White/IR Light: 3 variable output settings (0-300 lumens) /(0-120mW)
FUSION Sight Power Settings (Features Eight (8) Increments):
 – Visible Aiming Laser Red (635) <5 mW Low to 25 mW Max High
 – IR Aiming Laser <.7 mW Low to 25 mW Max High
 – IR Illuminator <.7 mW Low to 25 mW Max High

Features Overview

1. FUSION Sight allows rapid, accurate target acquisition with aiming laser and illuminator options as well as a reflex sight with built in iron sights, trajectory switch.

2. SureFire dual spectrum light features 2 illumination modes of white and IR output

3. Pressure pad controls light/laser/reflex and can be configured to front or back of rail as well as left or right side.

4. Dual battery management system allows quick and easy transition from primary to reserve power supply. You never throw out a unutilized battery again.

5. Optional 3X magnifier quickly and securely attaches and detaches to flip to side mount. This magnifier can be stowed for CQB engagement or used in-line for longer engagements.

6. Silicone triangle tiles along the left and right side of the FUSION SYSTEM mitigate heat from the barrel and can also be removed to allow the pressure pad to be placed in the forward or rearward position.

The post FUSION KMA556 appeared first on 1776 Sporting Goods.

Choose Lens:

A simple touch of a button will automatically adjust your point of impact for the distance to your target with the ATN Auxiliary Ballistic Laser 1500. This range-finding laser attaches to any ATN Smart HD day, night, or thermal riflescope and interacts with the scope’s ballistic calculator via Bluetooth, allowing operation with the scope’s controls. Its 5-1500 yard/meter range is accurate to within one yard or meter. It can add the distance to the target to videos of shots made by the smart scope. The Auxiliary Ballistic Laser includes an integrated sunshade and attaches to the riflescope with two screws. Made of hardened aluminum alloy, it is designed to withstand the recoil of high-caliber rifles. Power is supplied by one CR123A battery, which will last six months or 50,000 measurements.

• Waterproof
• Integrated sunshade
• Sends range to scope’s ballistic calculator, which automatically moves reticle without having to adjust turrets
• Integrated Bluetooth 4.1
• Stamps distance to target on video shot by Smart HD scope
• Recoil-resistant electronics
• 12 Hours of Continuous use



---

Ultra low power profile

12 hours continuous use

---

Sunshade

Acts as sunshade during bright daylight conditions.

---

 Recoil Resistant

Designed to withstand the pressures of High Caliber weapons. The ABL is built out of Hardened Aluminium Alloy with Impact Resistant Electronics.

---

Compatibility

Works with ATN Smart HD Day, Night and Thermal Riflescopes

---

The post ATN Auxiliary Ballistic Laser 1500 appeared first on 1776 Sporting Goods.

• Waterproof
• Integrated sunshade
• Sends range to scope’s ballistic calculator, which automatically moves reticle without having to adjust turrets
• Integrated Bluetooth 4.1
• Stamps distance to target on video shot by Smart HD scope
• Recoil-resistant electronics
• 12 Hours of Continuous use



---

Ultra low power profile

12 hours continuous use

---

Sunshade

Acts as sunshade during bright daylight conditions.

---

 Recoil Resistant

Designed to withstand the pressures of High Caliber weapons. The ABL is built out of Hardened Aluminium Alloy with Impact Resistant Electronics.

---

Compatibility

Works with ATN Smart HD Day, Night and Thermal Riflescopes

---

The post ATN Auxiliary Ballistic Laser 1000 appeared first on 1776 Sporting Goods.
